ParanTek - SOLUTION - Video Accessory Board

DCA-BI100

An optional IP module to encode BT.1120 data into IP (H.264) . Input Video: ParanTek BT.1120 to IP . Output Video: H.264 IP Streaming . Audio Input & Output (Line) . Alarm Inputs & Output (2 Inputs, 1 Output) . Micro-SD Memory Card (Video Saving) . RS485 Out (No Input supported) . Factory/System Reset . Compatible with DCC-1Z0, DCC-2S0, DCC-9410

DCA-2N0

An optional isolated DC-DC power module for camera boards. . Input: DC6~36V (Isolated) . Output: DC12V . Compatible for any Camera Modules . 32x32mm type 1-board (Weight: 8g)

DCA-IPSub

An optional module to enable additional functions for the DCC-1M0 . Audio Input & Output (Line) . Alarm Inputs & Output (2 Inputs, 1 Output) . Micro-SD Memory Card (Video Saving) . RS485 Out (No Input supported) . Factory/System Reset . Compatible with DCC-1M0

DCA-VC110

LVDS to HDMI Video Converter . Support 1ch of LVDS(Single 16bits mode). . Compatible with DCC-Z1020, DCC-2021 & DCC-3520
